Reference	22014
Brand	ARRASATE PR-80
Type	PNEUMATIC CLUTCH
Control	Conventional
Delivery time	Inmediatly
Year of manufacture
Country of origin	ESPAÑA
Location	Our warehouse

Technical features

Type: PR-80. Motor: 10 HP at 380V. Country of Origin: Spain. Table: 900 x 560 mm. Clearance: 350 mm. Weight: 5,050 kg. Strokes: 70. Distance between columns: 400 mm. Strokes: 20-120 mm. Throat depth: 300 mm. Hole in table: 360 x 360 mm. Sledge surface: 600 x 500 mm. Table height: 750 mm. Accessories: Mechanical over load system, auxiliary plate, pneumatic cushion, brand new automatic lubrication system, two-handed release, and foot pedal. Dimensions: 1,620 x 1,300 x 3,070 mm. With instruction manual. USED.

Technical details

Table hole mm	360 X 360
Table height mm	750
Storke mm	20-120
Dimensions (m)	1.62 X 1.3 X 3.07
Throat-Gap mm	300
Force (Tn)	80
Hits/min	70
Max. Distance Table-Ram mm	350
Table mm	900 X 560
Motor	10 HP A 380 V
Clearance between columns mm	400
Weight	5050
Ram surface mm	600 X 500
